Range -2.00 to 16.00 pH / -2.000 to 16.000 pH
±2000 mV 0.001 to 19999 ppm (AD1020 only) - 20.0 to 120.0°C (- 4.0 to 248.0°F)
Resolution 0.01 pH / 0.001 pH 0.1 mV (±999.9 mV) / 1 mV (outside)
0.001 ppm (0.001 to 9.999)
0.01 ppm (10.00 to 99.99)
0.1 ppm (100.0 to 999.9)
0.1°C (0.1°F)
Accuracy(@25°C/77°F)
±0.01 pH / ±0.002 pH
±0.2 mV up to ±699.9 mV
±0.5 mV up to ±999.9
Relative mV Offset ± 2000 mV
pH Calibration Up to 5 point calibration,
with 2 custom and 7 standard buffers (pH 1.68, 4.01, 6.86, 7.01, 9.18, 10.01, 12.45)
|
Temperature Manual |
or automatic, -20.0 to 120.0°C (-4.0 to 248.0°F) |
|
pH Electrode |
AD1131B |
|
Temperature Probe |
AD7662 |
|
Logging Interval |
5 seconds to 180 minutes |
|
Printer |
External serial printer |
|
PC Interface |
USB port |
|
Analog Output |
± 2000 mV |
|
Input Impedance |
1012 Ohm |
|
Environment |
0 to 50°C (32 to 122°F) RH max. 95% non-condensing |
|
Power Supply |
12 Vdc adapter |
|
Dimensions |
230 x 180 x 50 mm |
|
Weight |
1.8 kg |
